Using MinIO

Set up MinIO for self-hosted, S3-compatible object storage with full control and privacy.

Why Choose MinIO?

🏠 Self-Hosted: Complete control over your data and infrastructure
🔗 S3 Compatible: Drop-in replacement for AWS S3 API
💰 Cost Effective: No cloud provider fees - just your server costs
🔒 Private: Keep sensitive data on your own infrastructure
⚡ High Performance: Optimized for speed and throughput

🚀 Quick Start with Docker

1. Start MinIO Server

# Create data directory
mkdir -p ~/minio/data

# Start MinIO server
docker run -d \
  --name minio \
  -p 9000:9000 \
  -p 9001:9001 \
  -v ~/minio/data:/data \
  -e "MINIO_ROOT_USER=minioadmin" \
  -e "MINIO_ROOT_PASSWORD=minioadmin123" \
  quay.io/minio/minio server /data --console-address ":9001"

2. Access MinIO Console

Open http://localhost:9001 in your browser
Login with:
- Username: minioadmin
- Password: minioadmin123

3. Create a Bucket

Click "Create Bucket"
Enter bucket name (e.g., my-app-uploads)
Click "Create Bucket"

4. Create Access Keys

Go to "Identity" → "Service Accounts"
Click "Create service account"
Enter a name (e.g., "Upload Service")
Click "Create"
Save your Access Key and Secret Key

🏭 Production Docker Setup

Docker Compose Configuration

# docker-compose.yml
version: "3.8"

services:
  minio:
    image: quay.io/minio/minio:latest
    container_name: minio
    ports:
      - "9000:9000" # API
      - "9001:9001" # Console
    volumes:
      - minio_data:/data
    environment:
      MINIO_ROOT_USER: ${MINIO_ROOT_USER}
      MINIO_ROOT_PASSWORD: ${MINIO_ROOT_PASSWORD}
    command: server /data --console-address ":9001"
    restart: unless-stopped
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:9000/minio/health/live"]
      interval: 30s
      timeout: 20s
      retries: 3

volumes:
  minio_data:

Environment Variables

# .env
MINIO_ROOT_USER=your-admin-username
MINIO_ROOT_PASSWORD=your-secure-password-min-8-chars

Start Production Server

docker-compose up -d

🌐 Production Deployment

1. Reverse Proxy Setup (Nginx)

# /etc/nginx/sites-available/minio
server {
    listen 80;
    server_name uploads.yourdomain.com;

    location / {
        proxy_pass http://localhost:9000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Handle large uploads
        client_max_body_size 100M;
    }
}

# Console (optional - for admin access)
server {
    listen 80;
    server_name minio-console.yourdomain.com;

    location / {
        proxy_pass http://localhost:9001;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

2. SSL/TLS Setup

# Install Certbot
sudo apt install certbot python3-certbot-nginx

# Get SSL certificates
sudo certbot --nginx -d uploads.yourdomain.com
sudo certbot --nginx -d minio-console.yourdomain.com

🔧 Configure Your App

Add to your .env.local:

# MinIO Configuration
AWS_ACCESS_KEY_ID=your_minio_access_key
AWS_SECRET_ACCESS_KEY=your_minio_secret_key
AWS_ENDPOINT_URL=http://localhost:9000
# For production: AWS_ENDPOINT_URL=https://uploads.yourdomain.com
AWS_REGION=us-east-1
S3_BUCKET_NAME=my-app-uploads

# Optional: Custom public URL
MINIO_PUBLIC_URL=https://uploads.yourdomain.com

📝 Update Your Upload Configuration

// lib/upload.ts
import { createUploadConfig } from "pushduck/server";

export const { s3,  } = createUploadConfig()
  .provider("minio",{
    accessKeyId: process.env.AWS_ACCESS_KEY_ID!,
    secretAccessKey: process.env.AWS_SECRET_ACCESS_KEY!,
    endpoint: process.env.AWS_ENDPOINT_URL!,
    region: process.env.AWS_REGION!,
    bucket: process.env.S3_BUCKET_NAME!,
    // Force path-style URLs for MinIO
    forcePathStyle: true,
    // Optional: Custom public URL for file access
    publicUrl: process.env.MINIO_PUBLIC_URL,
  })
  .defaults({
    maxFileSize: "100MB", // MinIO handles large files well
    acl: "public-read",
  })
  .build();

🧪 Test Your Setup

npx @pushduck/cli@latest test --provider minio

This will verify your MinIO connection and upload a test file.

✅ You're Ready!

Your MinIO server is configured! Benefits:

Full control over your data
No cloud fees - just server costs
High performance for local/regional traffic
Complete privacy for sensitive files

🔒 Security Configuration

1. Bucket Policies

Set up access control for your bucket:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "AWS": "*"
      },
      "Action": "s3:GetObject",
      "Resource": "arn:aws:s3:::my-app-uploads/*"
    }
  ]
}

2. Access Key Management

Create restricted access keys:

// Service account with limited permissions
const uploadOnlyPolicy = {
  Version: "2012-10-17",
  Statement: [
    {
      Effect: "Allow",
      Action: ["s3:PutObject", "s3:PutObjectAcl", "s3:GetObject"],
      Resource: "arn:aws:s3:::my-app-uploads/*",
    },
  ],
};

3. Network Security

# docker-compose.yml with network isolation
version: "3.8"

services:
  minio:
    # ... other config
    networks:
      - minio-network
    ports:
      # Only expose what's needed
      - "127.0.0.1:9000:9000" # Bind to localhost only
      - "127.0.0.1:9001:9001"

networks:
  minio-network:
    driver: bridge

📊 Monitoring & Maintenance

Health Checks

// Add health monitoring
.hooks({
  onUploadStart: async () => {
    // Check MinIO connectivity
    const isHealthy = await checkMinIOHealth();
    if (!isHealthy) {
      throw new Error("MinIO server unavailable");
    }
  }
})

async function checkMinIOHealth() {
  try {
    const response = await fetch(`${process.env.AWS_ENDPOINT_URL}/minio/health/live`);
    return response.ok;
  } catch {
    return false;
  }
}

Backup Strategy

# Regular data backups
#!/bin/bash
# backup-minio.sh

BACKUP_DIR="/backups/minio/$(date +%Y-%m-%d)"
mkdir -p $BACKUP_DIR

# Backup MinIO data
docker run --rm \
  -v minio_data:/source:ro \
  -v $BACKUP_DIR:/backup \
  alpine tar czf /backup/minio-data.tar.gz -C /source .

# Backup configuration
docker exec minio mc admin config export /backup/

🚀 Performance Optimization

1. Storage Configuration

# Optimized for performance
services:
  minio:
    # ... other config
    environment:
      # Performance tuning
      MINIO_CACHE: "on"
      MINIO_CACHE_DRIVES: "/tmp/cache"
      MINIO_CACHE_QUOTA: "90"
    volumes:
      - minio_data:/data
      - /tmp/minio-cache:/tmp/cache # Fast SSD cache

2. Connection Optimization

// Optimize for high throughput
export const { s3,  } = createUploadConfig()
  .provider("minio",{
    // ... config
    maxRetries: 3,
    retryDelayOptions: {
      base: 300,
      customBackoff: (retryCount) => Math.pow(2, retryCount) * 100,
    },
    // Connection pooling
    maxSockets: 25,
    timeout: 120000,
  })
  .build();

🔧 Advanced Features

Multi-Tenant Setup

// Different buckets per tenant
const createTenantConfig = (tenantId: string) =>
  createUploadConfig()
    .provider("minio",{
      // ... base config
      bucket: `tenant-${tenantId}-uploads`,
    })
    .middleware(async ({ req }) => {
      const tenant = await getTenantFromRequest(req);
      return { tenantId: tenant.id };
    })
    .build();

Distributed Setup

# Multi-node MinIO cluster
version: "3.8"

services:
  minio1:
    image: quay.io/minio/minio:latest
    command: server http://minio{1...4}/data{1...2} --console-address ":9001"
    # ... configuration

  minio2:
    image: quay.io/minio/minio:latest
    command: server http://minio{1...4}/data{1...2} --console-address ":9001"
    # ... configuration

  # minio3, minio4...

Connection refused? → Check MinIO is running and port 9000 is accessible
Access denied? → Verify access keys and bucket permissions
CORS errors? → Set bucket policy to allow your domain
Slow uploads? → Check network connection and server resources
SSL errors? → Verify certificate configuration for custom domains

💡 Use Cases

Development Environment

Local testing without cloud dependency
Offline development for air-gapped environments
Cost-free development and testing

Production Scenarios

Data sovereignty requirements
High-security environments
Edge computing deployments
Hybrid cloud strategies

Next: Upload Your First Image or explore Google Cloud Storage
